Nozzle Vane Lineup - atect corporation

For Gasoline Engine
◆Responding to gasoline VG expected to rapidly expand in the near future～1000℃
Material	Current Method	Atect PIM Technology
Nickel-based super alloy (Inconel713C)	Lost-wax casting ※Adopted only in a few models of Porsche	Established mass production technology of High temperature resistant material such as Inconel713C by Atect PIM method

◆Development concept

Against the backdrop of environmental issues around the world, fuel efficiency improvement activities of the gasoline engine vehicle by using supercharging downsizing turbo has been trended.
A number of research papers have been established as themes of VGT(Variable Geometry Turbo), VGS(Variable Geometry System) and VG(Variable Geometry). However, because of the excessive performance and high cost, it is not as popular as diesel engine turbo cars. So atect will realize high performance and low cost by doing alloy development with the performance more than HK30 less than Inconel713C and production innovation by fully using IT technology, and is going to contribute the spread of gasoline engine cars and environmental problems.

◆Mechanical Characteristics
Items	Specification	Result	Judge
①Component analysis	Weight ratio of 9 elements	Within specification	OK
②Hardness （25℃）	162～195[Hv0.5]	188	OK
③High-temperature oxidation resistance（900℃）	Oxidation weight gain ≦33.5[g/m2]	-6.2	OK
④Tensile strength, elongation （25℃,800℃）	25℃：≧586.4[MPa] （Elongation≧25.3[%]）	606（Elongation 32%）	OK
④Tensile strength, elongation （25℃,800℃）	800℃：≧161.6[MPa]	237	OK
⑤Creep strength（850℃・40MPa）	≧53.5[h]	72.1（Unbroken, discontinued）	OK
⑥Fatigue strength（25℃）	1×10＾7cycle Maximum stress ≧366.5[MPa]	1×10＾7cycle(Unbloken) Maximum stress:370[MPa]	OK

◆Corresponding to the products by lost wax casting as mainstream and third party MIM ～700℃
Material	Current Method	Atect PIM Technology
Heat resistant stainless alloy (HK30)	Lost-wax casting, Fine blanking, MIM	Realize high performance and low cost by mass production technology
For Diesel Engine
